MIL-DTL-21248C
TABLE II. (Continued)
K
P
C 1/
V 1/
Nominal Ring Size
(Free gap)
(Inch)
(Inch)
(Inch)
(Inch)
Inch
mm
Max
Basic
Tol
Max
Max
1.188
30.2
.080
.078
.026
.012
1.250
31.7
.080
.078
.027
.012
1.312
33.3
.080
.078
.031
.012
1.375
34.9
.080
.078
.032
.012
1.438
36.5
.080
.078
.034
.012
1.500
38.1
.080
.120
.035
.012
1.562
39.7
.102
.125
.036
.012
1.625
41.3
.102
.125
.037
.012
1.688
42.9
.102
.125
.038
.012
1.750
44.4
.102
.125
.040
.012
1.772
45.0
.102
.125
.041
.012
1.812
46.0
.102
.125
.041
.012
1.875
47.6
.102
.125
.042
.012
1.969
50.0
.102
.125
.045
.012
2.000
50.8
.102
.125
.045
.012
2.062
52.4
.123
.125
.046
.015
2.125
54.0
.123
.125
.049
.015
2.156
54.8
.123
.125
+.015
.049
.015
2.250
57.1
.123
.125
-.002
.052
.015
2.312
58.7
.123
.125
.054
.015
2.375
60.3
.123
.125
.055
.015
2.438
61.9
.123
.125
.056
.015
2.500
63.5
.123
.125
.057
.015
2.559
65.0
.138
.125
.054
.015
2.625
66.7
.138
.125
.060
.015
2.688
68.3
.138
.125
.061
.015
2.750
69.8
.153
.125
.062
.015
2.875
73.0
.153
.125
.066
.015
2.938
74.6
.153
.125
.068
.015
3.000
76.2
.153
.125
.070
.015
3.062
77.8
.153
.125
.071
.015
3.125
79.4
.153
.125
.072
.015
3.156
80.2
.153
.125
.073
.015
3.250
82.5
.153
.125
.075
.015
3.346
85.0
.153
.125
.077
.015
10
