MS51830F
FIGURE 2. INSERT, FINE INTERNAL THREADS.
TABLE II. FINE INTERNAL THREADS.
DASH NO. |
INTERNAL THREAD SAE AS8879 UNJF-3B |
EXTERNAL THREAD FED- STD-H28/2 EXCEPT MODIFIED MINOR DIA. |
0C ±.005 |
D ±.010 |
0E REF |
K REF |
L ±.015 |
KEY DIMENSIONS |
T ±.030 |
|||
SIZE |
MINOR DIA |
M REF |
N REF |
P REF |
||||||||
201 |
.190-32 |
.3125-18UNC-2A |
.256 .249 |
.196 |
.070 |
.250 |
.220 |
.312 |
.068 |
.040 |
.160 |
.220 |
|
202 |
.250-28 |
.375-16UNC-2A |
.320 .312 |
.257 |
.070 |
.310 |
.284 |
.375 |
.068 |
.040 |
.190 |
.220 |
203 |
.3125-24 |
.4375-14UNC-2A |
.383 .375 |
.316 |
.070 |
.375 |
.345 |
.437 |
.068 |
.040 |
.190 |
.220 |
204 |
.375-24 |
.500-13UNC-2A |
.440 .432 |
.380 |
.070 |
.430 |
.407 |
.500 |
.068 |
.040 |
.190 |
.240 |
205 |
.4375-20 |
.5625-12 UNC-2A |
.503 .495 |
.445 |
.070 |
.495 |
.469 |
.562 |
.068 |
.040 |
.190 |
.270 |
|
206 |
.500-20 |
.625-11 UNC-2A |
.565 .551 |
.507 |
.070 |
.550 |
.532 |
.625 |
.068 |
.040 |
.190 |
.280 |
3
