INCH-POUND
MIL-DTL-27426C
22 SEPTEMBER 1998
SUPERSEDING
MIL-DTL-27426B
27 SEPTEMBER 1997
DETAIL SPECIFICATION
RINGS, RETAINING, SPIRAL
(UNIFORM CROSS SECTION)
This specification is approved for use by all
Departments and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers the procurement requirements for uniform
cross section spiral retaining rings used on shafts and in bearing housings.
1.2 Classification. Retaining rings will conform to one of the following
classifications and codes as specified (see 6.3).
Type
2A01
-
Medium Duty External Rings
Type
2A02
-
Heavy Duty External Rings
Type
2B01
-
Medium Duty Internal Rings
Type
2B02
-
Heavy Duty Internal Rings
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3
and 4 of this specification. This section does not include documents in other sections
of this specification or recommended for additional information or as examples. While
every effort has been made to ensure the completeness of this list, document users are
cautioned that they must meet all specified requirements documents cited in sections 3
and 4 of this specification, whether or not they are listed.
2.2
Government documents.
2.2.1 Specifications, standards and handbooks . The following specifications,
standards and handbooks form a part of this document to the extent specified herein.
Unless otherwise specified, the issues of these documents are those listed in the issue
of the Department of Defense Index of Specifications and Standards (DODISS) and
supplement thereto, cited in the solicitation (see 6.2).
Beneficial comments (recommendations, additions, deletions) and any pertinent data
which may be of use in improving this document should be addressed to : the Defense
Industrial Supply Center, (Code DISC-AESD), 700 Robbins Avenue, Philadelphia, PA
19111-5096, by using the Standardization Document Improvement Proposal (DD Form 1426)
appearing at the end of this document or by letter.
AMSC N/A
FSC 5325
DISTRIBUTION STATEMENT A .
Approved for public release; distribution is unlimited.
