MIL-DTL-22529 Grommet, Edging \(S/S By Nasm22529\)This specification covers three types of edging grommets; a plastic caterpillar style applied with an adhesive, and two spring-style, stainless steel based composite grommets requiring no adhesives. Edging grommets are used to provide abrasion protection of electrical current carrying wires and cable bundles routed through metal structures.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9


MIL-DTL-22529D (AS)
A voltage shall be applied between the copper rod (tube) and the aluminum
sheet per TABLE V.  These grommets are primarily intended to provide chafing
protection.
Table V
Grommet Type
Volts Potential
60 Hertz (Hz)
MIL-DTL-22529/1
500
MIL-DTL-22529/2
500
MS21266
1500
The specified voltage shall be reached in not less than ten seconds and not
more than thirty seconds.  The grommets shall conform to the requirements
specified in 3.2.1.
1
4
2.4
GROMMET
2.4
GROMMET ASSEMBLY
1
22
2.4
COPPER TUBE
5LB
OR ROD
1
10
2
C
GROMMET
A
5
A
B
A
D
T
GROMMET
MS21266
A-A
SECTION
FIGURE 2.
Load deformation test fixture.
