MIL-DTL-22529D (AS)
5.
PACKAGING
5.1 Packaging. For acquisition purposes, the packaging requirements shall
be as specified in the contract order (see 6.2). When actual packaging of
materiel is to be performed by DoD personnel, these personnel need to contact
the responsible packaging activity to ascertain requisite packaging
requirements. Packaging requirements are maintained by the Inventory Control
Point's packaging activity within the Military Department or Defense Agency,
or within the Military Department's System Command. Packaging data retrieval
is available from the managing Military Department's or Defense Agency's
automated packaging files, CD-ROM products, or by contacting the responsible
packaging activity.
6.
NOTES
(This section contains information of a general or explanatory nature
that may be helpful, but is not mandatory.)
6.1 Intended use. Plastic and composite grommets covered by this
specification are intended to protect from abrasion electrical current
carrying wire and cable bundles that are routed through metal structures. The
grommets are for use in locations where the ambient temperature does not
exceed temperatures shown in Table VI or in areas where there is risk of
adhesive failure or embrittlement of grommets. The grommets are intended for
edge dressing, odd shape holes and circular holes.
Table VI
Grommet Type
Continuous
Ambient Temperature
85°
MIL-DTL-22529/2
125°
Nylon MS 21266
145°
MIL-DTL-22529/1
275°
TFE MS21266
6.2 Acquisition requirements.
Acquisition documents should specify the
following:
a. Title, number, and date of this specification.
b. Applicable MS Part Numbers, MIL-DTL-22529/1 or /2.
c. The level of preservation and packaging required (see 5.1)
6.3
Definition.
6.3.1 Grommet assembly.
A grommet inserted into a 2-1/2 inch square
aluminum sheet.
6.4
Subject term (key word) listing.
Grommet,
assembly
Grommet,
composite
Grommet,
cushion, composite
Grommet,
plastic
8
